AiR Pro 36
The AiR Pro 36 is a 36 channel Mixing Console with Built-in Dual Effects Processor dual effects processor, designed for live, front-of-house touring and installation applications.
Features
Specifications
Downloads
AiR Pro 36
  • •

    36 inputs (32 Mic/Line + 2 Stereo Line Inputs).

  • •

    Built-in Dual Multi Effects Processor

  • •

    6 Sub Group with individual outputs.

  • •

    6 Aux Channels (4 Pre , 2 Post) & stereo Aux return.

  • •

    Individual + 48V Phantom switch on each channel

  • •

    Mono sub output with low frequency selection.

  • •

    100mm faders.

  • •

    Mix & Group Routing on each channel.

  • •

    100Hz Low cut one each mono channel.

  • •

    Stereo AUX Return.

  • •

    3-band EQ with Mid-sweep on mono inputs.

  • •

    3-band EQ on stereo inputs.

  • •

    Inserts On Mono Channel.

  • •

    PFL switch on each channel.

  • •

    Peak & Mute LED per channel.

  • •

    Headphones & Monitor outputs with level control.

  • •

    2-track RCA Input with level control.

  • •

    XLR & Jack main outputs.

  • •

    2-track RCA record output.

  • •

    12 V Lamp Socket

  • Model

    AiR Pro 36

    Nominal Gain (Mic/Line/Stereo Line)

    60dB/40dB/20dB

    Max Gain (Mic/Line/Stereo Line)

    80dB/60dB/40dB

    Input Levels Sensitivity
    Mic (Gain Min/Gain Max)

    -10dBu / -60dBu

    Line (Gain Min /Gain Max)

    +10dBu / -40dBu

    Stereo Line (Gain Min /Gain Max)

    +10dBu / -20dBu

    Input Impedance
    Mic Input

    1.5 KΩ Balanced

    Line input

    20KΩ Balanced /10KΩ Unbalanced

    Main Output level (Nominal / Max)

    +0dBu (0.775V RMS) / +20dBu (7.75V RMS)

    Frequency Response

    20Hz to 20KHz (+0/-1 dB)

    Total Harmonic Distortion

    < 0.02%

    Signal to Noise Ratio

    -80dB

    Clip indication

    5 dB prior to true clip

    Equalization
    Mono Mic [Treble/Mid(with sweep)/Bass]

    ±16dB @ 12KHz/140Hz-3KHz/80 Hz

    Stereo Mic/Line (Treble/Bass)

    ±16dB @ 12KHz/80 Hz

    EFX

    2 x 16EFX (EFX1 & EFX 2)

    Phantom Supply

    +48V (Individual Switch on each Channels)

    Dimensions (W x D x H)mm

    1105 x 520 x 130

    Net Weight (Kgs.)

    18
