DJX 975
The DJX 975 is a high quality Professional 5-channel DJ mixer from Studiomaster Professional with high quality DJ EFX & BPM.
Features
Specifications
Downloads
DJX 975
3-Band Kill EQ (-30 dB) & Gain control per channel.
Balanced MIC input with gain & 3 Band EQ (±12dB).
Cross fader Reverse & Normal mode switch with Flat & Steep curve switch.
CUE section with CUE/Main mix control & Blend / Split option.
5 DJ Friendly EFX ( Flanger, Phaser, HPF, LPF, Phatter )
Editable EFX parameters.
BPM Tap Switch
Intelligent LED BPM Counter.
EFX BPM SYNC (syncs EFX to BPM of Track).
Separate Master, Record & Booth RCA out.
Headphone Cue Mix facility with Cue blend switch.
Balanced XLR Master Output.
Model
DJX 975
Gain (Mic/Line)
40dB/0dB
Input Level Sensitivity (Mic/Line)
-40dB/0dB
Main Output levels (Nominal/Max)
0dBu(0.775V) / +18dBu(6.15V RMS)
Booth Output levels (Nominal/Max)
0dBu(0.775V) / +18dBu(6.15V RMS)
Frequency Response
20Hz-22KHz (+/-3dB)
Total Harmonic Distortion
0.07% @ 1KHz 0.1% @ 1KHz
Equalisation Line I/P (Treble/Mid/Bass)
+10/-12 dB @ 10KHz , +12/-24dB @ 1.3KHz ,
+12/-29dB @ 50Hz
Signal to Noise Ratio (Mic/Line)
60dB/82dB
Power Supply
230V AC/50Hz
Dimensions (WxDxH in mm)
278 x 302 x 106
Net Weight (Kgs.)
3.4
