Pro 16.3
The Pro 3 Series combines the simplicity of the Diamond Club series with the requirement of more complex professional applications.
Features
Specifications
Downloads
Pro 16.3
16 Mic/14 Line + 2 Mono/Stereo
Balanced Mic/Line inputs.
Monster (Mono-Stereo) Inputs for full flexibility.
Gain control with 3 Band EQ & mid-sweep on each channel.
4 Aux Send/level AB & Aux 4 AB returns on board.
L/R Pan/Bal control & Signal/Peak led per channel.
Master (L-R), Group (G1-G2), PFL Self illuminated switches per channel.
Aux 1/2 – Pre fader & Aux 3/4 – Post fader.
Group switchable to Main Mix/Mono or both.
Headphone & bargraph monitoring by selection of Mix/Group & Mono/PFL.
Stereo CD In/Record Out & ¼” Headphone out.
Balanced XLR Master Output.
Separate Mono Output with Level Control on Balanced XLR connector.
Switchable +48V Phantom on all channels except first 6 channels.
12 Segments LED Meter.
Operates on wide mains supply variation 150V-240V.
Model
Pro 16.3
Nominal Gain (Mic/Line/Stereo Line)
60dB/40dB/20dB
Max Gain (Mic/Line/Stereo Line)
80dB/60dB/40dB
Input Levels Sensitivity
Mic (Gain Min/Gain Max)
-10dBu / -60dBu
Line (Gain Min /Gain Max)
-10dBu / -40dBu
Stereo (Gain Min /Gain Max)
+10dBu / -20dBu
Input impedence
Mic Input
Typically 1.7K Ω balanced
Line input
17K Ω (Balanced) /8K Ω (Unbalanced)
Main Output level (Nominal / Max)
+0dBu (0.775V RMS) / +22dBu (10V RMS)
Main Output Impedance
<30 Ω
Frequency Response
20Hz to 20KHz (+0/-1 dB)
Total Harmonic Distortion
<0.1
Signal to Noise Ratio
-78 dB
Clip indication
5 dB prior to true clip
Equalisation
Mono Mic [Treble/Mid(with sweep)/Bass]
±16dB @ 12KHz/350Hz-6KHz/60 Hz
Stereo Mic/Line (Treble/Mid/Bass)
±16dB @ 12KHz/2.5 Hz/45 Hz
Phantom Supply
+48V (Ch 7-16)
Power Supply
150V~250V AC/50Hz
Dimensions (W x D x H in mm)
599 x 460 x 128
Net Weight (Kgs.)
10.6
