SWF 18200
The S-Series is our most comprehensive range of high-performance transducers designed to deliver powerful sound reproduction, suit a wide variety of enclosure designs, and perform reliably for years without losing their sonic qualities.
Features
Specifications
Video
Downloads
SWF 18200
High-quality 18” 2000W (RMS) 8Ω transducer with excellent sensitivity and excursion capabilities.
Assembled using high-quality Ferrite magnets, tightly-wound voice coils, and responsive paper cones.
Ventilated voice coil gap to reduce power compression, improve conversion efficiency, and superior cooling.
Heavy-duty die-cast frame with a wide flange for increased rigidity.
Engineered to suit a wide variety of enclosure designs to deliver high power, clarity, and punch.
Model
SWF 18200
Product Type
Subwoofer
Power Output (RMS / Peak) Watts
2000 / 4000
Frequency Range (Hz)
40-1200
Impedance (Ω)
8
Sensitivity (1w @ 1m) dB
96
Nominal Diameter (mm/inch)
475 / 640 / 18
Voice Coil Diameter (mm/Inch)
152.2 / 6
Voice Coil Material
Copper
Kind of Layer
Inside / Outside
Basket
Die-cast
Net Weight (Kg)
30.62
