VaK 40
The Studiomaster Professional Vak 40 is a fully wireless conferencing system with camera tracking, digital voting, and much more. Integrating state-of-the-art Digital Signal Processing technologies, premium-grade hardware, unmatched interoperability, and an easy user interface, the Vak 40 series is geared to deliver a powerful, and intuitive wireless conferencing experience.
Features
Specifications
Video
Downloads
VaK 40
  • •

    Professional wireless conference system with 4 operating modes, FIFO / LIFO / Limit / Chairman.

  • •

    Highly-flexible and customizable system supporting up to 200 units.

  • •

    10 secure UHF channels with editable frequencies for flexibility in complex applications.

  • •

    NOM (Number of Open Microphones) – Supports up to 4 active units.

  • •

    Remote microphone ON/OFF and shutdown.

  • •

    Built-in USB MP3 recorder with sequential file saving and storage.

  • •

    Intuitive camera tracking with industry-standard VISCA and PELCO D/P protocol compatibility.

  • •

    RS-232 and RS-485 camera controller interface.

  • •

    Easy sign-in and voting function for streamlined decision making.

  • •

    Automatic interference correction and anti-RF for dropout-free performance.

  • •

    DSP and noise gate for ambient noise suppression and audio clarity.

  • •

    Operating distance of up to 100 ft. (line of sight).

  • •

    User-friendly interface with responsive LCD touch screen.

  • •

    User-friendly interface with responsive LCD touch screen.

  • •

    User-friendly interface with responsive LCD touch screen.

  • •

    Easy-to-use, no operator required.

  • •

    Quick plug-and-play installation.

  • •

    Ideal for boardrooms, conference rooms, legislative chambers and other large and complex meeting scenarios.

  • •

    Sleek and classy 21” 2-bend gooseneck microphone with base.

  • •

    High-quality condenser microphone capsule for superior voice reproduction.

  • •

    Illuminated ON/OFF talk switch.

  • •

    Clear 2” TFT colour screen displays microphone ON/OFF status, connectivity status, selected channel number, unit ID, battery level, microphone ON time and analogue watch dial.

  • •

    LED ring to indicate ‘Mic Active’ status.

  • •

    Priority switch on the chairman unit to override all delegates during a discussion.

  • •

    Quick access switches to sign-in for voting function, increase/decrease volume and microphone number editing.

  • •

    Power supply options: Removable rechargeable battery or USB type-C connector (cable supplied).

  • •

    Long-lasting 20 hours battery life.

  • •

    Fully wireless for flexibility in fixed and mobile applications.

  • Vak 40.s (Main Controller)
    Frequency Range (Hz)

    45Hz-18kHz ±1dB

    Signal to Noise Ratio

    >60dB

    Operation Distance

    60m

    Output Connector

    XLR & 1/4" Jack

    Power Supply

    AC 240V

    Dimension (W x D X H) mm

    483 x 323 x 90

    Net Weight (Kg)

    5.1

    Vak 40.c (Chairman) And Vak 40.d (Delegate)
    RF Power Output

    15mW

    Priority Button

    Only on the Vak 40.c Chairman Unit

    Bandwidth

    30MHz

    Power Supply

    3.7V DC

    Length of MIC Tube

    21" / 533mm (2 Bends)

    Dimension (W x D x H) mm

    160 x 138 x 49

    Net Weight (Kg)

    0.76
