X 55
The X 55 is a 5 channel DJ mixer with a built-in USB MP3 media player & Bluetooth, 3-band kill EQ (-30 dB) and multiple inputs and outputs to let you mix in style.
Features
Specifications
Video
Downloads
X 55
3-band kill EQ (-30 dB) and gain control per channel.
Balanced XLR mic input with gain and 3-band EQ.
Built-in USB MP3 media player with wireless Bluetooth connectivity.
Crossfader flat / steep curve switch.
Headphone cue Mix with blend switch.
Separate master, record and booth RCA output.
¼” headphone output with level control.
Balanced XLR master output.
Ultra smooth and sturdy faders.
Model
X 55
Gain (Mic / Phono / Line)
40dB / 40dB / 0dB
Input Level Sensitivity (Mic / Phono / Line)
-40dBu / -40dBu / 0dBu
Main Output level (Nominal / Max)
0dBu (0.775V) /+18dBu (6.15V RMS)
Booth Output Levels (Nominal / Max)
0dBu(0.775V) Nominal / +18dBu(6.15V RMS) Max
Frequency Response
20Hz-22KHz (+/-3dB)
Total Harmonic Distortion
0.07% @ 1KHz 0.1% @ 1KHz
Equalisation Line I/P (Treble/Mid/Bass)
+10/-12dB @ 10kHz, +12/-24dB @ 1.3kHz, +12/-29dB @ 50Hz, Mic: ±12dB @ 10kHz / 2.5kHz / 70Hz
Signal to Noise Ratio (Mic/Line)
65dB / 82dB
Dimensions (W x D x H) mm
277 x 300 x 105
Net Weight (Kg)
3
