XPA 40
The Studiomaster Professional XPA 40 is a high power amplifier with a Thermal Management System (TMS) - our innovative temperature-controlled gain variation technology integrated into the circuitry.
Features
Specifications
Video
Downloads
XPA 40
Professional-grade high-power stereo amplifier.
Built-in crossover and bass boost switch.
High-quality balanced XLR and ¼” stereo jack input connectors.
3 switchable operational modes: stereo, mono, and bridge.
High-current toroidal transformers with high-endurance cores for greater transient response and low-noise even at 2Ω.
Sensitivity (0.775V or 1.2V) selection switch allows flexibility in connection of input sources.
The Limiter switch provided protects the speakers from damage due to distorted input signals.
Responsive rotary volume control knobs.
Low THD and high damping factor for excellent sound quality.
High-quality glass epoxy, double-sided PTH PCBs, and high-grade components ensure reliability even in tough ambient environs.
Intelligent cooling using low-noise variable speed fans and direct-mounted over-designed heatsinks.
Power Output
2 Ω (True RMS),20Hz-20kHz,1% THD
2 x 2000 W
2 Ω (EIA), 1kHz , 1%THD
2 x 3000 W
4 Ω (True RMS),20Hz-20kHz,1% THD
2 x 1400 W
4 Ω (EIA), 1kHz , 1%THD
2 x 2100 W
8 Ω (True RMS),20Hz-20kHz,1% THD
2 x 850 W
8 Ω (EIA), 1kHz , 1%THD
2 x 1200 W
Bridged Mode
4 Ω (True RMS), 20Hz-20kHz, 1% THD
4000 W
8 Ω (True RMS), 20Hz-20kHz, 1% THD
2800 W
Damping factor (8 Ω)
>400:1
Frequency Range
20Hz-20kHz (± 0.5dB)
Protection
Temperature, DC, RFI, short circuit, soft-start, overload
Input Connector (Per Channel)
XLR, jack stereo 6.3mm
Output Connector (Per Channel)
Speakon and Binding Post
Dimensions (W x D x H) mm
484 x 575 x 133 (3U)
Net Weight (Kg)
33
