AQUA 14
The Studiomaster Professional Aqua Series are a range Compact Professional Mixing Consoles designed for a large variety of applications.
Features
Specifications
Video
Downloads
AQUA 14
12 Mic/Line + 2 Stereo
2 Aux Sends – Aux + EFX (When internal FX is not used).
2 Sub groups with Individual outputs.
Globally Switched +48V Phantom Power.
3 Band EQ per Channel.
Mic / Line selectivity switch on each mono channel with 20 dB PAD for mic input.
Mix, Group & PFL Routing per channel.
L/R Pan control & signal LED per channel.
Headphone and monitor outputs with level control.
Stereo RCA Playback & record outputs.
Built in 24-bit Multi-FX processor with Tap Tempo.
FS mute jack to connect to a standard footswitch to switch On/Off internal EFX.
Balanced XLR Outputs.
Model
AQUA 14
Nominal Gain (Mic/Line/Stereo Line)
0dB/40dB/20dB
Max Gain (Mic/Line/Stereo Line)
80dB/60dB/40dB
Input Levels Sensitivity
Mic (Gain Min/Gain Max)
-10dBu/ -60dBu
Line (Gain Min /Gain Max)
+10dBu / -40dBu
Stereo Line (Gain Min / Gain Max)
+10dBu / -20dBu
Input Impedance
Mic Input
2KΩ Balanced
Line Input
20KΩ (Balanced) / 10KΩ (Unbalanced)
Main Output level (Nominal / Max)
0dBu (0.775V RMS) / +22dBu (10V RMS)
Main Output Impedance
75Ω
Frequency Response
20Hz to 20KHz (+0/-2 dB)
Total Harmonic Distortion
< 0.006%
Signal to Noise Ratio
85dB
Equalisation (Mic / Stereo Line)
-±15dB (12KHz HF / 2.5 KHz MF/60Hz LF) / ±15dB (12KHz HF / 2.5 KHz MF/80Hz LF)
Effect
16 Effects, 24-Bit EFX Processor
Phantom Supply
+48V
Dimensions (W x D x H) mm
538 x 317 x 134
Net Weight (Kgs.)
6.5
