D.Mix 20
Discontinued
The Studiomaster Professional D. Mix 20 digital mixer combines the best of what an LCD touchscreen can offer a digital with an intuitive interface for speed and precision in live mixing scenarios.
Features
Specifications
Video
Downloads
D.Mix 20
16 mono Input channels with assignable controls.
8 Channels Inserts.
2 Stereo input channels.
1 USB audio channels.
Full duplex USB port (allows for simultaneous recording & reproduction) for reproduction of digital audio data from a PC & recording mixing onto a PC..
2 integrated DSP’s with EQ, Noise Gate, Compressor / Limiter & Delay.
4 Aux Send outs & 4 Subgroup outs or 8 Aux outputs.
6 DCA groups.
100mm motor-driven fader.
24 bits/48kHz sampling rate.
User definable presets.
+48V Phantom power.
LCD touch screen for settings, routing and navigation.
XLR & Jack Main outputs & Stereo Control Room output.
Model
D. Mix 20
Gain (Mic/Line/Stereo Line)
50dB / 50 dB
Max Gain (Mic/Line)
70dB / 70 dB
Input Levels Sensitivity
Mic (Gain Min/Gain Max)
0 dBu / -50 dBu
Line (Gain Min /Gain Max)
+8 dBu / -40 dBu
Input Impedance
Mic Input
5K Balanced
Line input
19K Unbalanced
Main Output level (Nominal / Max)
0 dBu (0.775 V RMS) / +20 dBu (8V RMS)
Main Output Impedance
120 Ω
Frequency Response
20Hz to 20KHz (+0dB ± 1.5dB)
Total Harmonic Distortion
<0.05%
Signal to Noise Ratio
85dB
Equalisation
Mono Mic (Treble/Mid with Sweep/Bass)
±24dB (21 Hz – 19.2 KHZ)
Stereo Line (Treble/Mid-Hi/Mid-low/Bass)
±24dB (21 Hz – 19.2 KHZ)
EFX
32 – Bit EFX Processor
Phantom Supply
+48V
Dimensions (W x D x H)mm
445 x 355 x 140
Net Weight (Kgs.)
7.25
